Flat Panel

www.peerlessmounts.com 800.865.2112

To verify mount compatibility with any LCD, plasma, or projector model use MountFinder

MODELS

U n i v e r s a l Mo d e l s :

Standard Fasteners*

lcFs-100 Black

lcFs-100s Silver

SCREEN ADAPTER

n i v e r s a l Mo d e l s :

Includes universal screen adapter to accommodate

VESA

75 and 100 mounting holes

SPECIFICATIONS

di M e n s i o n s : (W x H x D)

23" x 60.75"-80" x 24"

(58.4 x 154.3-203.2 x 61 cm)

W i v e l : ±90°

Ma x lo a d :

Freestanding: 25 lb (11.3 kg)

Bolted down: 40 lb (18.1 kg)

sh i P We i g h t : 26 lb (11.8 kg)

Mo U n t i n g

sU r F a c e s : All ﬂoor surfaces

Stands and Carts

Pedestal Stand

For 10" to 30" LCD Screens

 VESA

75 and 100

compliant

 Non-VESA

adapter

plates also available

 Adjustable height

from 60.75" to 80"

 Feet can move

inward along the

tubular structure if

required

 180° of swivel at the

head (up to 90° on

each side)

 Can be used

freestanding (up

to 25 lb) or bolted

down (up to 40 lb)

 Comes with

hardware to bolt to

concrete ﬂooring

* Includes standard hardware (hex or Phillips) for attaching screen to mount
